High Definition Rotating LED Screen

High Definition Rotating LED Screen
Features Gallery Product Description Request A Quote
Type: Other Machining Services
Material Capabilities: Aluminum, Steel Alloys
Micro Machining Or Not: Micro Machining
Material: Aluminum Alloy
Application: Automotive
Warranty: 1year

High Definition Rotating LED Screen


Eye Catching Rotating LED Screen


Smart Rotating LED Screen

Basic Infomation
Place of Origin: China
Brand Name: CAIYI
Certification: CE, FCC, ROHS
Model Number: Moving Structure
Payment & Shipping Terms
Packaging Details: Simple box, waterproof cabinet, die-cast aluminum cabinet
Delivery Time: 3-5days
Payment Terms: T/T, L/C, Western Union, Paypal
Supply Ability: 1000pieces per day
Product Description

Rotating screen instruction

Rotating screen is a machine, electricity, screen integrated rotation of multimedia motion display equipment, its main principle is through the motor drive screen (steel frame) in the rotating frame rotates 360 degrees or at any Angle.

Rotating motion and display content can be asynchronous, also can be controlled by software program, mechanical rotation and screen video, text content synchronization.

The rotating screen mainly includes the following parts: rotating base, rotating body (display frame, motor, reducer, driver,
rotating bearing, central shaft, conductive ring, mesh ring), controller, remote control, display screen, etc.

External equipment: other control software and other control equipment.

The significance of the rotating screen is to add motion to the multimedia equipment, so that the form and choice of multimedia become more colorful and richer.
High Definition Rotating LED Screen 0

Technical features:

The rotating shaft core and the steel frame of the screen body can be manufactured and installed separately, or it can be
manufactured as a whole. Multiple rotating bodies can be linked, or monomer can move independently, and arbitrary polygon and circle can be customized.

Control features: power back to zero program, graphic and video synchronization program. Remote control, manual switch, external mobile phone, tablet and other central control.

Technical parameters

Rotary shaft core integration:
Rotating core
Parameter number
Sheet metal, steel frame material
Steel pipe and plate: Q235, 304 stainless steel optional
Accuracy of mechanical installation
Stepper, servo motor + reducer
60-180 flange optional, power: 200w-7500w, suitable for reducer
Motor repeated positioning accuracy
Mechanical rotation positioning accuracy
0.01-0.1 degrees
Mechanical bearing accuracy
Conductive ring, mesh ring
Carbon Brush, Silver Plated, Gold Plated (custom on demand)


Control mode

* Remote control: advantages recommended custom remote control key function, control screen according to the setting program rotation, stop, power back to zero.
* Manual control, automatic cycle control, other wired control.
* Mobile phone control, computer control.
* Induction /AI control (custom development).

Software features
1. Support a variety of built-in programs and a variety of signals
2. Support background synchronous or asynchronous
3. Rotation at any Angle is supported
4. Support for third party control
High Definition Rotating LED Screen 1
